Semi Auto High Viscosity Liquid Cream Filling Machine

1 / 5

Semi Auto High Viscosity Liquid Cream Filling Machine

Customization:	Available
After-sales Service:	Technnical Support for Whole Life of Machine
Warranty:	12 Months

Send Inquiry

Product Description

Basic Information

Model NO.

DLF-210QS

Type

Volumetric Filling Machine

Automatic Grade

Semi-Automatic

Material Type

Paste

Filling Valve Head

Single-Head

Dosing Device

Rotor

Filling Principle

Pressure

Structure

Linear

Packaging

Bottle

Packaging Material

Plastic

Product Name

Liquid Cream Filling Machine

Filling Range

10-20000ml

Filling Accuracy

Pump Type

Gear Pump

Material

SUS304

Production Capacity

1000PCS/Min.

Key Features

Rotor Pump Technology Uses rotor pump based on volume measurement, ideal for viscous and sticky liquids, especially those containing solid materials.

Microcomputer Control Precise control over filling volume, rotating speed, and filling speed with integrated data storage.

Easy Maintenance Designed for quick disassembly and assembly without the need for additional tools.

Durable Construction Full stainless steel structure ensures longevity and easy cleaning for hygienic operations.

Technical Specifications

Model No.	DLF-210QS
Pump Type	Rotor Pump (SUS304)
Filling Range	5-10000ml (5g-10kg)
Production Capacity	12-24 bottles/min
Rotating Speed	5-400 r/min
Max. Liquid Viscosity	100,000 CP
Power Supply	AC220V; 50/60HZ; 1P; 700W
Dimension	390 * 600 * 600mm
Machine Weight	35kg
Package Size	65.00cm * 55.00cm * 55.00cm
Gross Weight	55.000kg

Frequently Asked Questions

What types of products can the DLF-210QS fill?

This machine is specifically designed for viscous and sticky liquids, such as creams, pastes, and liquids containing solid particles.

How accurate is the filling process?

The machine offers high precision with a filling accuracy of approximately 2%, controlled via a microcomputer system.

Is the machine difficult to clean between batches?

No, the machine features a stainless steel structure and is designed for easy disassembly without tools, making the cleaning process fast and simple.

What is the maximum viscosity this machine can handle?

The DLF-210QS can handle high-viscosity materials up to a maximum of 100,000 CP.

What are the power requirements for operation?

The machine operates on a standard AC220V, 50/60Hz single-phase power supply with a power consumption of 700W.

Can the filling speed be adjusted?

Yes, the rotating speed (5-400 r/min) and filling speed are fully adjustable through the microcomputer control panel.
